| Categories | Lithium Battery Spot Welder |
|---|---|
| Brand Name: | AWT |
| Model Number: | HD-2119 |
| Certification: | as required |
| Place of Origin: | China |
| MOQ: | 1 |
| Price: | negotiable |
| Payment Terms: | T/T |
| Supply Ability: | 50 sets Per Month |
| Delivery Time: | 7-10 days |
| Packaging Details: | 1000mm×800mm×1200mm |
| name: | auto body spot welder |
| Batter Cell: | 18650 32650 |
| Power Supply: | AC380V 5000A |
| Application: | E-bike Electric car |
| Drive Mode: | Pedal |
| Welding Time: | 1.0ms—30.0ms |
| Company Info. |
| Supo (Xiamen) Intelligent Equipment Co.,Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
E-bike Electric car Lithium Battery Spot Welder for 18650 32650 HD-2119 380V 5000A
Product model:HD-2119
Feature
1. High performance CPU control, 128 x 64, LCD blue screen display
2. (Single) Double pulse energy storage welding to reduce welding spatter;
3. Electronic voltage stabilization automatic compensation function, welding output is not affected by network voltage fluctuation;
4. The width of pulse 1 and 2 can be adjusted (discharge time)
5. Function of current monitoring and warning of abnormal current.
6. 10 welding procedures are stored to facilitate setting and calling.
7. With radio (RFI) and electromagnetic dry (EMI) protection functions;
8. The pulse waveform can be adjusted (long, medium and short) to suit fine welding.
| Input power supply | AC 220 v / + 50 hz |
| Air pressure | 0.5-0.8 MPa |
| Pre-welding Current | 00-99 |
| Welding Current | 00-99 |
| Welding Time | 1.0ms—30.0ms (0.1ms tolerance adjustable) |
| Drive method | Pneumatic or Pedal |
| Weight | 75KG |
| Dimension | 900L x 700W x 1250H |
Feature:
1. Load current check and electrostatic current control of switching mode are beneficial to high quality welding control.
2. 4KHz high-frequency modulation inverters control is conducive to high-speed response and high-quality welding control.
3. The application of two-stage electrification function is conducive to overcoming the coating problem of welded workpiece and adapting to various technological requirements.
4. Slow-up and slow-down function is conducive to restraining the splash phenomenon in welding and the switching of eight welding specifications is conducive to fast changing welding parameters according to different welding requirements.
5. It has the function of current monitoring. it will give an alarm after judging the value beyond the set value,
| Spot Welder | Input Voltage | Nickel Thickness | Price Level |
| Stored Energy Welder | AC 220V/50HZ 5000A | Nickel Alloy≦0.2mm Pure Nicel≦0.15mm | Low |
| DC Inverter Welder | AC 380V/50HZ 5000A | Nickel Alloy≦0.2mm Pure Nicel≦0.15mm | Middle |
| DC Inverter Welder | AC 380V/50HZ 8000A | Pure Nicel≦0.2mm,slot Nickel≦0.4mm | High |
| Transistor Welder | PD-6000A/10000A | Pure Nicel≦0.2mm,slot Nickel≦0.4mm | Expensive |
|
