| Categories | Welded Wire Mesh |
|---|---|
| Brand Name: | Huacheng |
| Model Number: | HC-1 |
| Certification: | ISO9001:2015 |
| Place of Origin: | Anping, China |
| MOQ: | 1 roll |
| Price: | USD3-25 per roll |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 400 rolls per day |
| Delivery Time: | 3-15 days |
| Packaging Details: | water-proof paper, pallets, wooden case, etc |
| name: | welded wire mesh |
| mesh width: | 3',4',5' |
| type: | welding |
| Aperture: | 1/4"-8"mm |
| Wire Gauge: | 0.5mm-14mm |
| material: | low carbon steel wire, galvanized wire |
| Packing: | moister-proof paper, PVC film, nude packed |
| using: | industry, building, mine, field, fence guard, agriculture, etc |
Welded Wire Mesh
Gauge: BWG12 TO BWG24
Mesh: 3/8",5/8",1/4",1/2",3/4",1" to 6" to 7"
Length: 10' to 300'
Packing: moister-proof paper, PVC film, nude packed
Material: Low carbon steel wire, stainless steel wire
Welded wire mesh is level and flat in surface with sturdy structure. Welded wire mesh is used in industry and agriculture building, transportation and mining for all such purposes as poultry houses, egg baskets, runway enclosures, draining rack, fruit drying screen, fence.
| Stainless Steel Welded Wire Mesh | ||||||||||||||||||||||||
| Opening | Wire Diameter<BWG> | |||||||||||||||||||||||
| In inch | In metric unit(mm) | |||||||||||||||||||||||
| 2" x 3" | 50mm x 75mm | 2.0mm,2.5mm,1.65mm | ||||||||||||||||||||||
| 3" x 3" | 75mm x 75mm | 2.67mm,2.41mm,2.11mm,1.83mm,1.65mm | ||||||||||||||||||||||
| 2" x 4" | 50mm x 100mm | 2.11mm,2.5mm | ||||||||||||||||||||||
| 4" x 4" | 100mm x 100mm | 2.0mm,2.5mm | ||||||||||||||||||||||
| Technical Note: 1.Standard roll length: 30m;width: 0.5m to 1.8m 2.Special sizes available at request 3.Packing: in waterproof paper in rolls. Custom packing available at request. | ||||||||||||||||||||||||
| Specification List of Welded Wire Mesh | ||||||||||||||||||||||||
| Opening | Wire Diameter<BWG> | |||||||||||||||||||||||
| In inch | In metric unit(mm) | |||||||||||||||||||||||
| 1/4" x 1/4" | 6.4mm x 6.4mm | 22,23,24 | ||||||||||||||||||||||
| 3/8" x 3/8" | 10.6mm x 10.6mm | 19,20,21,22 | ||||||||||||||||||||||
| 1/2" x 1/2" | 12.7mm x 12.7mm | 16,17,18,19,20,21,22,23 | ||||||||||||||||||||||
| 5/8" x 5/8" | 16mm x 16mm | 18,19,20,21, | ||||||||||||||||||||||
| 3/4" x 3/4" | 19.1mm x 19.1mm | 16,17,18,19,20,21 | ||||||||||||||||||||||
| 1" x 1/2" | 25.4mm x 12.7mm | 16,17,18,19,20,21 | ||||||||||||||||||||||
| 1-1/2" x 1-1/2" | 38mm x 38mm | 14,15,16,17,18,19 | ||||||||||||||||||||||
| 1" x 2" | 25.4mm x 50.8mm | 14,15,16 | ||||||||||||||||||||||
| 2" x 2" | 50.8mm x 50.8mm | 12,13,14,15,16 | ||||||||||||||||||||||
Technical Note:
| ||||||||||||||||||||||||
| GAUGE | MESH | W X L | N.W/ROLL (KGS) | LOAD CAPABILITY (ROLLS/20 ' ) |
| BWG14 | 1" X 1" | 3' X 100' | 56 | 240 |
| 2" X 1" | 3' X 100' | 41 | 245 | |
| BWG15 | 1" X 1" | 3' X 100' | 42 | 275 |
| 2" X 1" | 3' X 100' | 32 | 285 | |
| BWG16 | 1" X 1" | 3' X 100' | 35 | 300 |
| 2" X 1" | 3' X 100' | 27 | 360 | |
| 3/4" X 3/4" | 3' X 100' | 47 | 300 | |
| BWG17 | 1" X 1" | 3' X 100' | 28 | 360 |
| 1" X 1/2" | 3' X 100' | 41 | 330 | |
| 3/4" X 3/4" | 3' X 100' | 36 | 335 | |
| BWG18 | 1" X 1" | 3' X 100' | 19 | 475 |
| 1/2" X 1/2" | 3' X 100' | 40 | 415 | |
| 1" X 1/2" | 3' X 100' | 29 | 415 | |
| 3/4" X 3/4" | 3' X 100' | 26 | 440 | |
| BWG19 | 1" X 1" | 3' X 100' | 14 | 565 |
| 1/2" X 1/2" | 3' X 100' | 28 | 490 | |
| 1" X 1/2" | 3' X 100' | 20 | 525 | |
| 3/4" X 3/4" | 3' X 100' | 19 | 545 | |
| BWG20 | 1" X 1" | 3' X 100' | 10 | 740 |
| 1/2" X 1/2" | 3' X 100' | 20 | 580 | |
| 3/4" X 3/4" | 3' X 100' | 13 | 630 | |
| BWG21 | 1/2" X 1/2" | 3' X 100' | 16 | 700 |
| BWG22 | 1/2" X 1/2" | 3' X 100' | 13 | 800 |
| BWG23 | 1/4" X 1/4" | 3' X 100' | 20 | 800 |
