JIS G 3465 Drill Steel Pipe , Seamless Steel Tubes for Drilling / Mineral Exploration

Name: JIS G 3465 Drill Steel Pipe Seamless Steel Tubes for Drilling Mineral Exploration
Brand: Torich
Price: 1 USD

JIS G 3465 Drill Steel Pipe , Seamless Steel Tubes for Drilling / Mineral Exploration

Categories	Geological Drilling Steel Tubes
Place of Origin:	China
Brand Name:	Torich
Certification:	ISO 9001 ISO14001 TS 16949 DNV LR KR
Model Number:	JIS G 3465
MOQ:	5tons
Price:	Negotiation
Packaging Details:	IN BUNDLES
Delivery Time:	30-60DAYS
Payment Terms:	T/T L/C
Supply Ability:	50000 TONS PER YEAR
Application:	For Drill Rod, Casing Tube, Core Tube

Contact Now

Add to Cart

Company Info.

Torich International Limited

View Contact Details

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

JIS G 3465 STM-C-540 Seamless Drill Steel Pipes and Tubes for Drilling for mineral exploration

JIS G 3465 Seamless Steel Tubes for Drilling

Dimension:OD 30-150mm, WT: 3-20mm

Application :for Drill rod, Casing tube, Core tube

MECHANICAL PROPERTIES MIN
Steel grade	Tensile strength Mpa	Yeild point or proof stress Mpa	Elongation %
STM-C-540	540	-	18
STM-C-640	640	-	16
STM-R-590	590	375	18
STM-R-690	690	440	16
STM-R-780	780	520	15
STM-R-830	830	590	10

Outside Diameter,wall Thickness and Mass (for casing Tube)
Nominal diameter	Outside diameter mm	Inside diameter	Wall thickness mm	Unit mass kg/m
43	43	37	3	2.96
53	53	47	3	3.7
63	63	57	3	4.44
73	73	67	3	5.18
83	83	77	3	5.92
97	97	90	3.5	8.07
112	112	105	3.5	9.36
127	127	118	4.5	13.6
142	142	133	4.5	15.3
Outside Diameter,wall Thickness and Mass (for Core tube)
Nominal diameter	Outside diameter mm	Inside diameter	Wall thickness mm	Unit mass kg/m
34	34	26.5	3.75	2.8
44	44	34.5	4.75	4.6
54	54	44.5	4.75	5.77
64	64	54.5	4.75	6.94
74	74	64.5	4.75	8.11
84	84	74.5	4.75	9.28
99	99	88.5	5.25	12.1
114	114	103.5	5.25	14.1
129	129	118.5	5.25	16
144	144	133.5	5.25	18
180	180	168	6	25.7
Outside Diameter,wall Thickness and Mass (for Drill Rod)
Nominal diameter	Outside diameter mm	Inside diameter	Wall thickness mm	Unit mass kg/m
33.5	33.5	23	5.25	3.66
40.5	40.5	31	4.75	4.19
42	42	32	5	4.56
50	40	37	6.5	6.97
