Coalescing Separation Diesel Fuel Oil Purifier DSP Explosionproof Type

Categories Fuel Oil Purifier
Brand Name: HLA
Model Number: DSP
Certification: CE,ISO9001,ISO14001,BV
Place of Origin: Chongqing,China
MOQ: 1 set
Price: Negotiation
Payment Terms: T/T, L/C, Western Union
Supply Ability: 500sets/year
Delivery Time: 10 days
Packaging Details: Wooden case suitable for sea transportation and air transportation
Condition: Brand new
Flow rate: 10-300L/min
Water content: ≤100ppm
Working pressure: ≤ 0.4 Mpa
Filtering precision: ≤1 micron
Operation mode: Automatilc & Manual
Power supply: By customized
Color: Optional
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
  • Submit Buying Request
    • Product Details
    • Company Profile

    Coalescing Separation Diesel Fuel Oil Purifier DSP Explosionproof Type

    Coalescing Separation Diesel Fuel Oil Purifier DSP Explosionproof Type


    Application:

    DSP Coalescence-separation oil purifier is designed to remove free water and dissolved water from lube oils or diesel fuel,coalescing filter will make the free and dissolved water from small molecule to big drop, then separation filter remove the water drop by gravity, falling into the water tank. It removes the particles by stages of filters and cleanness up to NAS grade 6. It is applicable for on line running with light oil filled, turbine oil filled and lubricating oil filled systems, especially good for water- leakage systems.


    Features:

    ◆ Rapidly removing large amount free & emulsified water from Oil and water content reach 100 PPM.

    ◆ The coalesced oil takes the least restricted path to exit and rises or floats through the media to the top of the bulk liquid surface.

    ◆ The working conditions of all the parts are displayed clearly, monitoring, alarming, action control and safety stop enable the oil filtration machine to run online.

    ◆ Multilayer filtration can remove the impurities through coarse filter, protecting filter, and fine filer.


    Technical Specification:

    ModelDSP010DSP020DSP030DSP050DSP100DSP150DSP200DSP300
    Capacity(L/min)10203050100150200300
    Working pressure≤ 0.4 Mpa
    Filtering precision≤1 micron
    Water content≤100 ppm
    Cleanness levelNAS 6 grade
    Continuous work≥200 hr
    No failure running≥5000 hr
    Power supply380V, 50HZ, 3PH ( or Customized )
    Working noise65 dB
    Total power (kw)11122.5345
    Inlet/outlet(mm)3232323244505865
    Weight (kg)300350400450520760900980

    Dimension

    (mm)

    L12001300140015001600165016501750
    W7508009009501000105011001200
    H14001500155016001650170017501850

    Our Honor and Quality Certificate:
    China Famous brand Oil Purifier Company
    Golden-supplier for China National Electric power Group
    Golden-Supplier for ALSTOM, SIEMENS, SCHNEIDER Company
    ISO9001 products quality certificate
    CE Products safety certificate
    SGS Products local testing report
    More than 10 years and 50 countries and districts exporting experience

    Our After-sales:
    Engineer is available for local installation.
    Long time warranty from the delivery time.
    24 hours online service question and answer.
    More than 10 years experience


    Our Main Series Products as following:
    DVP-Double vacuum Transformer oil purifier
    VPM-Movable insulating oil purification cart
    DYK-Electric transformer air drying equipments
    TVP-Online Turbine oil treatment
    DSP-Fuel oil filtration unit
    LVP-Lubricating oil purifier/hydraulic oil purification
    AP-oil regeneration system, waste oil recycling
    PR-Press paper filter machine
    DK-Portable oil piurifier,oil filtering,oil filter
    ZJY dielectric strength tester for transformer oil
    EE36-Oil moisture sensor
    Oil purifier parts and various oil testing equipments
